Systemctl 命令详解及使用教程

·1669 words·8 mins
Linux Linux Systemctl Systemd
Table of Contents

在本教程中,我们将向您介绍在运行systemd的linux系统上如何使用systemctl命令工具有效的控制系统和服务。

Systemctl 介绍
#

Systemctl是一个systemd工具,主要负责控制systemd系统和服务管理器。

Systemd是一个系统管理守护进程、工具和库的集合,用于取代System V初始进程。Systemd的功能是用于集中管理和配置类UNIX系统。

在Linux生态系统中,Systemd被部署到了大多数的标准Linux发行版中,只有为数不多的几个发行版尚未部署。Systemd通常是所有其它守护进程的父进程,但并非总是如此。

开始Systemd和Systemctl 基础工具之旅
#

01.首先检查系统上是否安装了systemd以及当前安装的Systemd的版本是什么?
#


# systemd --version
systemd 249 (249.11-0ubuntu3.9)
+PAM +AUDIT +SELINUX +APPARMOR +IMA +SMACK +SECCOMP +GCRYPT +GNUTLS +OPENSSL +ACL +BLKID +CURL +ELFUTILS +FIDO2 +IDN2 -IDN +IPTC +KMOD +LIBCRYPTSETUP +LIBFDISK +PCRE2 -PWQUALITY -P11KIT -QRENCODE +BZIP2 +LZ4 +XZ +ZLIB +ZSTD -XKBCOMMON +UTMP +SYSVINIT default-hierarchy=unified

从上面的例子可以清楚地看出,我们已经安装了systemd 249版本。

02.检查systemd和systemctl的二进制文件和库的安装位置。
#


# whereis systemd
systemd: /usr/lib/systemd /etc/systemd /usr/share/systemd /usr/share/man/man1/systemd.1.gz
# whereis systemctl
systemctl: /usr/bin/systemctl /usr/share/man/man1/systemctl.1.gz

03.检查systemd是否正在运行。
#


# ps -eaf | grep [s]ystemd
root         1     0  0 16:27 ?        00:00:00 /usr/lib/systemd/systemd --switched-root --system --deserialize 23
root       444     1  0 16:27 ?        00:00:00 /usr/lib/systemd/systemd-journald
root       469     1  0 16:27 ?        00:00:00 /usr/lib/systemd/systemd-udevd
root       555     1  0 16:27 ?        00:00:00 /usr/lib/systemd/systemd-logind
dbus       556     1  0 16:27 ?        00:00:00 /bin/dbus-daemon --system --address=systemd: --nofork --nopidfile --systemd-activation

注意:systemd作为父守护进程运行(PID = 1)。 在上面的命令ps中使用(-e)选择所有进程,( – a)选择除会话前导之外的所有进程和(-f)选择完整格式列表(即-eaf)。

另请注意上面示例中的方括号以及其他示例。 Square Bracket表达式是grep的字符类模式匹配的一部分。

04.分析systemd启动过程
#


# systemd-analyze
Startup finished in 487ms (kernel) + 2.776s (initrd) + 20.229s (userspace) = 23.493s

05.分析每个进程在引导时花费的时间
#


# systemd-analyze blame
8.565s mariadb.service
7.991s webmin.service
6.095s postfix.service
4.311s httpd.service
3.926s firewalld.service
3.780s kdump.service
3.238s tuned.service
1.712s network.service
1.394s lvm2-monitor.service
1.126s systemd-logind.service
....

06.分析启动时的关键链
#


# systemd-analyze critical-chain
The time after the unit is active or started is printed after the "@" character.
The time the unit takes to start is printed after the "+" character.
multi-user.target @20.222s
└─mariadb.service @11.657s +8.565s
└─network.target @11.168s
└─network.service @9.456s +1.712s
└─NetworkManager.service @8.858s +596ms
└─firewalld.service @4.931s +3.926s
└─basic.target @4.916s
└─sockets.target @4.916s
└─dbus.socket @4.916s
└─sysinit.target @4.905s
└─systemd-update-utmp.service @4.864s +39ms
└─auditd.service @4.563s +301ms
└─systemd-tmpfiles-setup.service @4.485s +69ms
└─rhel-import-state.service @4.342s +142ms
└─local-fs.target @4.324s
└─boot.mount @4.286s +31ms
└─systemd-fsck@dev-disk-by\x2duuid-79f594ad\x2da332\x2d4730\x2dbb5f\x2d85d19608096
└─dev-disk-by\x2duuid-79f594ad\x2da332\x2d4730\x2dbb5f\x2d85d196080964.device @4

重要:Systemctl接受服务(.service),挂载点(.mount),套接字(.socket)和设备(.device)作为单位。

07.列出所有可用的单位
#


# systemctl list-unit-files

UNIT FILE                                   STATE
proc-sys-fs-binfmt_misc.automount           static
dev-hugepages.mount                         static
dev-mqueue.mount                            static
proc-sys-fs-binfmt_misc.mount               static
sys-fs-fuse-connections.mount               static
sys-kernel-config.mount                     static
sys-kernel-debug.mount                      static
tmp.mount                                   disabled
brandbot.path                               disabled
.....

08.列出所有运行单元
#

<pre><code class="lang-bash">
# systemctl list-units
UNIT                                        LOAD   ACTIVE SUB       DESCRIPTION
proc-sys-fs-binfmt_misc.automount           loaded active waiting   Arbitrary Executable File Formats File Syste
sys-devices-pc...0-1:0:0:0-block-sr0.device loaded active plugged   VBOX_CD-ROM
sys-devices-pc...:00:03.0-net-enp0s3.device loaded active plugged   PRO/1000 MT Desktop Adapter
sys-devices-pc...00:05.0-sound-card0.device loaded active plugged   82801AA AC'97 Audio Controller
sys-devices-pc...:0:0-block-sda-sda1.device loaded active plugged   VBOX_HARDDISK
sys-devices-pc...:0:0-block-sda-sda2.device loaded active plugged   LVM PV Qzyo3l-qYaL-uRUa-Cjuk-pljo-qKtX-VgBQ8
sys-devices-pc...0-2:0:0:0-block-sda.device loaded active plugged   VBOX_HARDDISK
sys-devices-pl...erial8250-tty-ttyS0.device loaded active plugged   /sys/devices/platform/serial8250/tty/ttyS0
sys-devices-pl...erial8250-tty-ttyS1.device loaded active plugged   /sys/devices/platform/serial8250/tty/ttyS1
sys-devices-pl...erial8250-tty-ttyS2.device loaded active plugged   /sys/devices/platform/serial8250/tty/ttyS2
sys-devices-pl...erial8250-tty-ttyS3.device loaded active plugged   /sys/devices/platform/serial8250/tty/ttyS3
sys-devices-virtual-block-dm\x2d0.device    loaded active plugged   /sys/devices/virtual/block/dm-0
sys-devices-virtual-block-dm\x2d1.device    loaded active plugged   /sys/devices/virtual/block/dm-1
sys-module-configfs.device                  loaded active plugged   /sys/module/configfs
...
</code></pre>

09.列出所有失败的单元
#


# systemctl --failed

UNIT          LOAD   ACTIVE SUB    DESCRIPTION
kdump.service loaded failed failed Crash recovery kernel arming
LOAD   = Reflects whether the unit definition was properly loaded.
ACTIVE = The high-level unit activation state, i.e. generalization of SUB.
SUB    = The low-level unit activation state, values depend on unit type.
1 loaded units listed. Pass --all to see loaded but inactive units, too.
To show all installed unit files use 'systemctl list-unit-files'.

10.检查单元(cron.service)是否启用?
#


# systemctl is-enabled crond.service
enabled

11.检查单元或服务是否正在运行?
#


systemctl status firewalld.service
firewalld.service - firewalld - dynamic firewall daemon
Loaded: loaded (/usr/lib/systemd/system/firewalld.service; enabled)
Active: active (running) since Tue 2018-04-28 16:27:55 IST; 34min ago
Main PID: 549 (firewalld)
CGroup: /system.slice/firewalld.service
└─549 /usr/bin/python -Es /usr/sbin/firewalld --nofork --nopid
Apr 28 16:27:51 tecmint systemd[1]: Starting firewalld - dynamic firewall daemon...
Apr 28 16:27:55 tecmint systemd[1]: Started firewalld - dynamic firewall daemon.

12.列出所有服务(包括启用和禁用)
#


# systemctl list-unit-files --type=service
UNIT FILE                                   STATE
arp-ethers.service                          disabled
auditd.service                              enabled
autovt@.service                             disabled
blk-availability.service                    disabled
brandbot.service                            static
collectd.service                            disabled
console-getty.service                       disabled
console-shell.service                       disabled
cpupower.service                            disabled
crond.service                               enabled
dbus-org.fedoraproject.FirewallD1.service   enabled
....

13.如何在Linux中启动,重新启动,停止,重新加载和检查服务(httpd.service)的状态
#


# systemctl start httpd.service
# systemctl restart httpd.service
# systemctl stop httpd.service
# systemctl reload httpd.service
# systemctl status httpd.service
httpd.service - The Apache HTTP Server
Loaded: loaded (/usr/lib/systemd/system/httpd.service; enabled)
Active: active (running) since Tue 2018-04-28 17:21:30 IST; 6s ago
Process: 2876 ExecStop=/bin/kill -WINCH ${MAINPID} (code=exited, status=0/SUCCESS)
Main PID: 2881 (httpd)
Status: "Processing requests..."
CGroup: /system.slice/httpd.service
├─2881 /usr/sbin/httpd -DFOREGROUND
├─2884 /usr/sbin/httpd -DFOREGROUND
├─2885 /usr/sbin/httpd -DFOREGROUND
├─2886 /usr/sbin/httpd -DFOREGROUND
├─2887 /usr/sbin/httpd -DFOREGROUND
└─2888 /usr/sbin/httpd -DFOREGROUND
Apr 28 17:21:30 tecmint systemd[1]: Starting The Apache HTTP Server...
Apr 28 17:21:30 tecmint httpd[2881]: AH00558: httpd: Could not reliably determine the server's fully q...ssage
Apr 28 17:21:30 tecmint systemd[1]: Started The Apache HTTP Server.
Hint: Some lines were ellipsized, use -l to show in full.

注意:当我们使用systemctl等启动,重启,停止和重载等命令时,我们将不会在终端上获得任何输出,只有status命令会打印输出。

14.如何在引导时激活服务并启用或禁用服务(系统引导时自动启动服务)
#


# systemctl is-active httpd.service
# systemctl enable httpd.service
# systemctl disable httpd.service

15.如何屏蔽(使其无法启动)或取消屏蔽服务(httpd.service)
#


ln -s '/dev/null' '/etc/systemd/system/httpd.service'
# systemctl unmask httpd.service
rm '/etc/systemd/system/httpd.service'

16.如何使用systemctl命令终止服务
#


# systemctl kill httpd
# systemctl status httpd
httpd.service - The Apache HTTP Server
Loaded: loaded (/usr/lib/systemd/system/httpd.service; enabled)
Active: failed (Result: exit-code) since Tue 2018-04-28 18:01:42 IST; 28min ago
Main PID: 2881 (code=exited, status=0/SUCCESS)
Status: "Total requests: 0; Current requests/sec: 0; Current traffic:   0 B/sec"
Apr 28 17:37:29 tecmint systemd[1]: httpd.service: Got notification message from PID 2881, but recepti...bled.
Apr 28 17:37:29 tecmint systemd[1]: httpd.service: Got notification message from PID 2881, but recepti...bled.
Apr 28 17:37:39 tecmint systemd[1]: httpd.service: Got notification message from PID 2881, but recepti...bled.
Apr 28 17:37:39 tecmint systemd[1]: httpd.service: Got notification message from PID 2881, but recepti...bled.
Apr 28 17:37:49 tecmint systemd[1]: httpd.service: Got notification message from PID 2881, but recepti...bled.
Apr 28 17:37:49 tecmint systemd[1]: httpd.service: Got notification message from PID 2881, but recepti...bled.
Apr 28 17:37:59 tecmint systemd[1]: httpd.service: Got notification message from PID 2881, but recepti...bled.
Apr 28 17:37:59 tecmint systemd[1]: httpd.service: Got notification message from PID 2881, but recepti...bled.
Apr 28 18:01:42 tecmint systemd[1]: httpd.service: control process exited, code=exited status=226
Apr 28 18:01:42 tecmint systemd[1]: Unit httpd.service entered failed state.
Hint: Some lines were ellipsized, use -l to show in full.

使用Systemctl控制和管理挂载点
#

17.列出所有系统安装点
#


# systemctl list-unit-files --type=mount
UNIT FILE                     STATE
dev-hugepages.mount           static
dev-mqueue.mount              static
proc-sys-fs-binfmt_misc.mount static
sys-fs-fuse-connections.mount static
sys-kernel-config.mount       static
sys-kernel-debug.mount        static
tmp.mount                     disabled

18.如何装载,卸载,重新装载,重新装载系统装载点,以及检查系统上装载点的状态
#


# systemctl start tmp.mount
# systemctl stop tmp.mount
# systemctl restart tmp.mount
# systemctl reload tmp.mount
# systemctl status tmp.mount
tmp.mount - Temporary Directory
Loaded: loaded (/usr/lib/systemd/system/tmp.mount; disabled)
Active: active (mounted) since Tue 2018-04-28 17:46:06 IST; 2min 48s ago
Where: /tmp
What: tmpfs
Docs: man:hier(7)
http://www.freedesktop.org/wiki/Software/systemd/APIFileSystems
Process: 3908 ExecMount=/bin/mount tmpfs /tmp -t tmpfs -o mode=1777,strictatime (code=exited, status=0/SUCCESS)
Apr 28 17:46:06 tecmint systemd[1]: Mounting Temporary Directory...
Apr 28 17:46:06 tecmint systemd[1]: tmp.mount: Directory /tmp to mount over is not empty, mounting anyway.
Apr 28 17:46:06 tecmint systemd[1]: Mounted Temporary Directory.

19.如何在引导时激活,启用或禁用装入点(在系统引导时自动装入)
#


# systemctl is-active tmp.mount
# systemctl enable tmp.mount
# systemctl disable  tmp.mount

20.如何在Linux中屏蔽(使其无法启动)或取消屏蔽挂载点
#


# systemctl mask tmp.mount
ln -s '/dev/null' '/etc/systemd/system/tmp.mount'
# systemctl unmask tmp.mount
rm '/etc/systemd/system/tmp.mount'

使用Systemctl控制和管理套接字
#

21.列出所有可用的系统套接字
#


# systemctl list-unit-files --type=socket
UNIT FILE                    STATE
dbus.socket                  static
dm-event.socket              enabled
lvm2-lvmetad.socket          enabled
rsyncd.socket                disabled
sshd.socket                  disabled
syslog.socket                static
systemd-initctl.socket       static
systemd-journald.socket      static
systemd-shutdownd.socket     static
systemd-udevd-control.socket static
systemd-udevd-kernel.socket  static
11 unit files listed.

22.如何在Linux中启动,重新启动,停止,重新加载和检查套接字的状态(例如:cups.socket)
#


# systemctl start cups.socket
# systemctl restart cups.socket
# systemctl stop cups.socket
# systemctl reload cups.socket
# systemctl status cups.socket
cups.socket - CUPS Printing Service Sockets
Loaded: loaded (/usr/lib/systemd/system/cups.socket; enabled)
Active: active (listening) since Tue 2015-04-28 18:10:59 IST; 8s ago
Listen: /var/run/cups/cups.sock (Stream)
Apr 28 18:10:59 tecmint systemd[1]: Starting CUPS Printing Service Sockets.
Apr 28 18:10:59 tecmint systemd[1]: Listening on CUPS Printing Service Sockets.

23.如何激活套接字并在引导时启用或禁用(在系统引导时自动启动套接字)
#


# systemctl is-active cups.socket
# systemctl enable cups.socket
# systemctl disable cups.socket

24.如何屏蔽(使其无法启动)或取消屏蔽插座(cups.socket)
#


# systemctl mask cups.socket
ln -s '/dev/null' '/etc/systemd/system/cups.socket'
# systemctl unmask cups.socket
rm '/etc/systemd/system/cups.socket'

服务的CPU利用率(份额)
#

25.获取服务的当前CPU份额(比如httpd)
#


# systemctl show -p CPUShares httpd.service
CPUShares=1024

注意:每个服务的默认值都为CPUShare = 1024.您可以增加/减少进程的CPU份额。

26.将服务的CPU份额(httpd.service)限制为2000 CPUShares /
#


# systemctl set-property httpd.service CPUShares=2000
# systemctl show -p CPUShares httpd.service
CPUShares=2000

注意:为服务设置CPUShare时,会创建一个名为service的目录(httpd.service.d),其中包含一个包含CPUShare Limit信息的文件90-CPUShares.conf。 您可以将文件视为:


# vi /etc/systemd/system/httpd.service.d/90-CPUShares.conf
[Service]
CPUShares=2000

27.检查服务的所有配置详细信息
#


# systemctl show httpd
Id=httpd.service
Names=httpd.service
Requires=basic.target
Wants=system.slice
WantedBy=multi-user.target
Conflicts=shutdown.target
Before=shutdown.target multi-user.target
After=network.target remote-fs.target nss-lookup.target systemd-journald.socket basic.target system.slice
Description=The Apache HTTP Server
LoadState=loaded
ActiveState=active
SubState=running
FragmentPath=/usr/lib/systemd/system/httpd.service
....

28.分析服务的关键链(httpd)
#


# systemd-analyze critical-chain httpd.service
The time after the unit is active or started is printed after the "@" character.
The time the unit takes to start is printed after the "+" character.
httpd.service +142ms
└─network.target @11.168s
└─network.service @9.456s +1.712s
└─NetworkManager.service @8.858s +596ms
└─firewalld.service @4.931s +3.926s
└─basic.target @4.916s
└─sockets.target @4.916s
└─dbus.socket @4.916s
└─sysinit.target @4.905s
└─systemd-update-utmp.service @4.864s +39ms
└─auditd.service @4.563s +301ms
└─systemd-tmpfiles-setup.service @4.485s +69ms
└─rhel-import-state.service @4.342s +142ms
└─local-fs.target @4.324s
└─boot.mount @4.286s +31ms
└─systemd-fsck@dev-disk-by\x2duuid-79f594ad\x2da332\x2d4730\x2dbb5f\x2d85d196080964.service @4.092s +149ms
└─dev-disk-by\x2duuid-79f594ad\x2da332\x2d4730\x2dbb5f\x2d85d196080964.device @4.092s

29.获取服务的依赖项列表(httpd)
#


# systemctl list-dependencies httpd.service
httpd.service
├─system.slice
└─basic.target
├─firewalld.service
├─microcode.service
├─rhel-autorelabel-mark.service
├─rhel-autorelabel.service
├─rhel-configure.service
├─rhel-dmesg.service
├─rhel-loadmodules.service
├─paths.target
├─slices.target
│ ├─-.slice
│ └─system.slice
├─sockets.target
│ ├─dbus.socket
....

30.按层次列出控制组
#


# systemd-cgls
├─1 /usr/lib/systemd/systemd --switched-root --system --deserialize 23
├─user.slice
│ └─user-0.slice
│   └─session-1.scope
│     ├─2498 sshd: root@pts/0
│     ├─2500 -bash
│     ├─4521 systemd-cgls
│     └─4522 systemd-cgls
└─system.slice
├─httpd.service
│ ├─4440 /usr/sbin/httpd -DFOREGROUND
│ ├─4442 /usr/sbin/httpd -DFOREGROUND
│ ├─4443 /usr/sbin/httpd -DFOREGROUND
│ ├─4444 /usr/sbin/httpd -DFOREGROUND
│ ├─4445 /usr/sbin/httpd -DFOREGROUND
│ └─4446 /usr/sbin/httpd -DFOREGROUND
├─polkit.service
│ └─721 /usr/lib/polkit-1/polkitd --no-debug
....

31.根据CPU,内存,输入和输出列出控制组
#


# systemd-cgtop
Path                                                              Tasks   %CPU   Memory  Input/s Output/s
/                                                                    83    1.0   437.8M        -        -
/system.slice                                                         -    0.1        -        -        -
/system.slice/mariadb.service                                         2    0.1        -        -        -
/system.slice/tuned.service                                           1    0.0        -        -        -
/system.slice/httpd.service                                           6    0.0        -        -        -
/system.slice/NetworkManager.service                                  1      -        -        -        -
/system.slice/atop.service                                            1      -        -        -        -
/system.slice/atopacct.service                                        1      -        -        -        -
/system.slice/auditd.service                                          1      -        -        -        -
/system.slice/crond.service                                           1      -        -        -        -
/system.slice/dbus.service                                            1      -        -        -        -
/system.slice/firewalld.service                                       1      -        -        -        -
/system.slice/lvm2-lvmetad.service                                    1      -        -        -        -
/system.slice/polkit.service                                          1      -        -        -        -
/system.slice/postfix.service                                         3      -        -        -        -
/system.slice/rsyslog.service                                         1      -        -        -        -
/system.slice/system-getty.slice/getty@tty1.service                   1      -        -        -        -
/system.slice/systemd-journald.service                                1      -        -        -        -
/system.slice/systemd-logind.service                                  1      -        -        -        -
/system.slice/systemd-udevd.service                                   1      -        -        -        -
/system.slice/webmin.service                                          1      -        -        -        -
/user.slice/user-0.slice/session-1.scope                              3      -        -        -        -

控制系统运行级别
#

32.如何启动系统救援模式
#


# systemctl rescue
Broadcast message from root@tecmint on pts/0 (Wed 2015-04-29 11:31:18 IST):
The system is going down to rescue mode NOW!

33.如何进入紧急模式
#


# systemctl emergency
Welcome to emergency mode! After logging in, type "journalctl -xb" to view
system logs, "systemctl reboot" to reboot, "systemctl default" to try again
to boot into default mode.

34.列出当前使用的运行级别
#


# systemctl get-default
multi-user.target

35.如何启动Runlevel 5 aka图形模式
#


# systemctl isolate runlevel5.target
OR
# systemctl isolate graphical.target

36.如何启动Runlevel 3又称多用户模式(命令行)
#


# systemctl isolate runlevel3.target
OR
# systemctl isolate multiuser.target

37.如何将多用户模式或图形模式设置为默认运行级别
#


# systemctl set-default runlevel3.target
# systemctl set-default runlevel5.target

38.如何重启,暂停,暂停,休眠或将系统置于混合睡眠状态
#


# systemctl reboot
# systemctl halt
# systemctl suspend
# systemctl hibernate
# systemctl hybrid-sleep

对于那些可能不了解跑步水平及其作用的人。

  • 运行级别0:关闭并关闭系统电源
  • 运行级别1:救援?维护模式
  • 运行级别3:多用户,无图形系统
  • 运行级别4:多用户,无图形系统
  • 运行级别5:多用户,图形系统
  • 运行级别6:关闭并重新启动机器

Related

CentOS和Ubuntu,哪个更适合你的Linux服务器
·116 words·1 min
Linux CentOS Data Center Linux Server Ubuntu
10 Useful Tips for Using the Exclamation Mark (!) in Linux
·428 words·3 mins
Bash Linux Shell
Updating Embedded Linux System Images: Wind River Linux vs Ubuntu Core
·1027 words·5 mins
Embedded Linux Linux System Image Update Wind River Linux
